10B-6 AIR BAG SYSTEM
SDM connector “G66”
Diagnosis
Diagnostic Trouble Code (DTC)
The AIR BAG DIAGNOSTIC SYSTEM CHECK must always be the starting point of any air bag system diagno-
sis. The AIR BAG DIAGNOSTIC SYSTEM CHECK checks for proper “AIR BAG” warning lamp operation and
checks for air bag diagnostic trouble codes (DTCs) using SUZUKI scan tool.
TERMINAL CIRCUIT TERMINAL CIRCUIT
G66-1 – G66-20 Side air bag (inflator)
module (passenger side)
(if equipped)
High
G66-2 – G66-21 Low
G66-3 – G66-22 –
G66-4 – G66-23
Passenger air bag
(inflator) module (if equipped)
Low
G66-5 Side sensor (passenger side)
(if equipped)
Low G66-24 High
G66-6 Side sensor (driver side)
(if equipped)
Low G66-25 –
G66-7 – G66-26 Driver air bag (inflator)
module
Low
G66-8 – G66-27 High
G66-9 – G66-28 Data link connector (DLC)
G66-10 – G66-29 –
G66-11 – G66-30 “AIR BAG” warning lamp
G66-12 – G66-31 Ground
G66-13 – G66-32 Ignition switch (power source)
G66-14 – G66-33
Driver pretensioner
High
G66-15 – G66-34 Low
G66-16 Side sensor (passenger side)
(if equipped)
High G66-35
Passenger pretensioner
Low
G66-17 Side sensor (driver side)
(if equipped)
High G66-36 High
G66-18 Side air bag (inflator)
module (driver side)
(if equipped)
Low
G66-19 High
WARNING:
To avoid deployment when troubleshooting the air bag system, do not use electrical test equipment
such as a battery powered or AC powered voltmeter, ohmmeter, etc., or any type of electrical equip-
ment other than that specified in this manual. Do not use a non-powered probe type tester.
Instructions in this manual must be followed carefully, otherwise personal injury may result.
