AIR BAG SYSTEM 10B-21
Special tool
(A) : 09932-76010
[A] : Fig. for Step 1 and 2 1. DLC “G09”
[B] : Fig. for Step 3 2. Scan tool
[C] : Fig. for Step 4 3. SDM connector “G66”
[D] : Fig. for Step 5
(A)
(A)
“G66-28”
“G09-7”
“G09-05”
“G09-04”
(A)
[A] [B]
[C] [D]
1
3
1
(A)
“G09-16”
1
NOTE:
Upon completion of inspection and repair work, perform following items.
• Reconnect all air bag system components, ensure all components are properly mounted.
• Repeat AIR BAG DIAGNOSTIC SYSTEM CHECK to confirm that the trouble has been corrected.
