AIR BAG SYSTEM 10B-51
Special tool
(A) : 09932-76010
[A] : Fig. for STEP 2 (DTC B1064)
[B] : Fig. for STEP 2 (DTC B1066)
1. SDM connector “G66”
[A]
“G66-6”
“G66-17”
[B]
“G66-5”
“G66-16”
(A) (A)
1
1
NOTE:
Upon completion of inspection and repair work, perform the following items.
• Reconnect all air bag system components, ensure all components are properly mounted.
• Clear diagnostic trouble code (Refer to DTC CLEARANCE), if any.
• Repeat AIR BAG DIAGNOSTIC SYSTEM CHECK to confirm that the trouble has been corrected.
To Next Page
