AIR BAG SYSTEM 10B-61
Special tool
(A) : 09932-76010
(B) : 09932-75010
(C) : 09932-78310
DTC B1083 : Side Air Bag (Driver Side) Initiator Circuit Short to Ground
DTC B1087 : Side Air Bag (Passenger Side) Initiator Circuit Short to Ground
NOTE:
Upon completion of inspection and repair work, perform the following items.
• Reconnect all air bag system components, ensure all components are properly mounted.
• Clear diagnostic trouble code (Refer to DTC CLEARANCE), if any.
• Repeat AIR BAG DIAGNOSTIC SYSTEM CHECK to confirm that the trouble has been corrected.
Step Action Yes No
1 1) With ignition switch OFF, disconnect side air
bag (inflator) module connector “G69” or
“G70” under front seat cushion.
2) Check proper connection to applicable side
air bag (inflator) module at terminals in
“G69” or “G70” connector.
3) If OK, then connect Special Tools (B) and
(C) to side air bag (inflator) module connec-
tor “G69” or “G70” disconnected at the step
1).
With ignition switch ON, is DTC B1083 or
B1087 still current?
Go to step 2. Ignition switch OFF.
Replace applicable front
seat back referring to
“FRONT SEAT” in Section
9.
2 1) With ignition switch OFF, disconnect Special
Tools (B) and (C) from “G69” or “G70” con-
nector and SDM connector “G66” from SDM
respectively.
2) Release shorting bar in SDM connector
inserting release tool (1) included in special
tool (A).
3) Measure resistance with connected Special
tool (A).
• DTC B1083 : between “G66-19” terminal
and body ground, and between “G66-18”
terminal and body ground.
• DTC B1087 : between “G66-20” terminal
and body ground, and between “G66-21”
terminal and body ground.
Is resistance infinity?
Substitute a known-good
SDM and recheck.
DTC B1083 :
Repair short from “WHT/
RED” or “WHT/GRN” wire
circuit to ground.
DTC B1087:
Repair short from “RED/
BLK” or “RED/YEL” wire
circuit to ground.
To Next Page
