10B-78 AIR BAG SYSTEM
6) Disconnect side sensor connector sliding connector outer (1)
as shown.
INSPECTION
• Check sensor (1) for dents, crack, deformation.
• Check sensor connector (sensor side and harness side),
lock mechanism or sensor lead wire for damage, crack,
scorching or melting.
• Check connector terminals for bent, corrosion or rust.
If any faulty condition is found in above checks, replace.
1
1
CAUTION:
• Never disassemble side sensor.
• Sensor should be replaced when it was dropped from a
height of 90 cm (3 ft) or more.
1
