ANTILOCK BRAKE SYSTEM (ABS) 5E-7
1. Battery 9. ABS hydraulic unit/control module assembly 17. Left-rear wheel speed sensor
2. Main fuses 10. Terminal arrangement of ABS hydraulic unit/con-
trol module assembly
18. Right-front wheel speed sensor
3. Ignition switch 11. ABS fail-safe relay (Solenoid valve relay) 19. Left-front wheel speed sensor
4. Circuit fuses 12. ABS pump motor relay 20. Data link connector
5. Combination meter 13. Pump motor 21. To ECM, TCM, SDM and P/S control module (if
equipped)
6. ABS warning lamp 14. Solenoid valves 22. Stop lamp
7. Brake warning lamp 15. Blank 23. Stop lamp switch
8. Warning lamp driver module (for ABS) 16. Right-rear wheel speed sensor 24. G sensor (For 4WD model only)
Wire color
B : Black Br : Brown R : Red
B/R : Black/Red G : Green V/W : Violet/White
B/W : Black/White G/R : Green/Red W/B : White/Black
Bl/B : Blue/Black G/W : Green/White W/Bl : White/Blue
Bl/R : Blue/Red Or : Orange W/R : White/Red
Bl/W : Blue/White Or/Bl : Orange/Blue
TERMINAL CIRCUIT
E20
1–
2 Stop lamp switch
3 Right-front wheel speed sensor (+)
4 Right-front wheel speed sensor (–)
5–
6 Right-rear wheel speed sensor (–)
7 Right-rear wheel speed sensor (+)
8–
9–
10 “EBD” warning lamp (Brake warning lamp)
11 G sensor (For 4WD model only)
12 –
13 Ground (for G sensor) (For 4WD model only)
14 ABS warning lamp
15 Left-front wheel speed sensor (+)
16 Left-front wheel speed sensor (–)
17 –
18 Ignition switch
19 Left-rear wheel speed sensor (+)
20 Left-rear wheel speed sensor (–)
21 Data link connector
22 Ground (for ABS pump motor)
23 ABS pump motor relay
24 Ground (for ABS control module)
25 ABS fail-safe relay
