ANTILOCK BRAKE SYSTEM (ABS) 5E-25
6 1) Install ABS wheel speed sensor to knuckle.
2) Tighten sensor bolt to specified torque and check that
there is no clearance between sensor and knuckle.
Is it OK?
Go to Step 7. Replace ABS wheel
speed sensor.
7 Referring to “Reference” of “FRONT WHEEL SPEED SEN-
SOR” and/or “Reference” of “REAR WHEEL SPEED SEN-
SOR” in this section, check output voltage or waveform.
Is specified voltage and/or waveform obtained?
Substitute a known-
good ABS hydraulic
unit/control module
assembly and
recheck.
Replace sensor and
recheck.
Step Action Yes No
