SYNRAD FH Series Flyer Operator’s Manual Version 3.4
104
Tracking hardware
DC power supply
The FH Flyer marking head incorporates an internal +15 VDC, 400 mA power supply output that can
p
ower a part sensor and position encoder as long as the combined current load does not exceed 400 mA. If
your I/O components sink or source a total of more than 400 mA, you must provide an appropriately-sized
DC power supply to power your I/O devices.
Power supply specifications
Table 5-3 lists electrical specifications when choosing an external DC power supply to power your input/
output circuits.
Table 5-3 Power supply specifications
Function Specications
Input Voltage User determined
Output Voltage Select output voltage based on encoder and part sensor
requirements within the range of +5.0–24.0 VDC
