By design, input IN0 is considered the ‘start mark’ input. When the Test Mark Mode is Auto, this input
is expected to be “Set” in the Wait Digital Before Piece command on the Drawing’s Automation tab or in a
WaitDigitalState Event Builder command in On Before Mark Session or On Before Mark Piece stages of
the automation loop. Note; however, that subsequent marks will not re until the state of IN0 transitions
from active to inactive during or after the previous mark.
The IN0 input state need not be specied on the Automation tab when Test Mark Mode is set to Manual
because pressing the Test Mark button initiates a mark session.
Important Note: When the Fast Acting Safety Interlock (FASI) is enabled, input IN3 must be active
in order for the laser to re during a mark. To ensure that the custom test mark does
not begin until FASI is enabled, you should always specify that IN3 in the Wait
Digital Before Piece command be “Set” before the automation loop can continue.
Outputs
FH Flyer is able to set or clear outputs (OUT0–OUT7) when marking a custom test mark. This output
capability is available when using any Set Digital commands on the Drawing’s Automation tab or when using
SetDigitalState Event Builder commands during On Before Mark Session, On Before Mark Piece, On
After Mark Piece, and On After Mark Session stages of the automation loop. The On Abort Session
event is not a valid custom test mark state.
Remember that in WinMark Pro’s Automation loop, On Before Mark Session and On After Mark Ses-
sion events run only once before/after a marking session while On Before Mark Piece and On After Mark
Piece events run before/after each individual piece. In a custom test mark application however, each indi-
vidual mark is considered a mark session meaning that On Before Mark Session / On After Mark Session
events are run for each piece that is marked.
General specifications
Table 6-22 FH Series Flyer marking head specifications
Parameter Marking Head Model Number: FHFLxx-xxx
1
Lens Focal Length 370 mm 200 mm 125 mm 125 HP
2
80 mm
Marking Specications
Field Size, nominal, mm 198 × 198 110 × 110 74 × 74 66 × 66 27 × 27
(in.) (7.8 × 7.8) (4.3 × 4.3) (2.9 × 2.9) (2.6 × 2.6) (1.0 × 1.0)
Spot Size, 1/e
2
, µm 540 290 180 180 116
(in.) (0.021) (0.011) (0.007) (0.007) (0.005)
Working Distance
3
, typical, mm 350 ±5 190 ±3 128 ±2 125 ±2 74 ±1
(in.) (13.78) (7.48) (5.04) (4.92) (2.91)
Depth of Field, typical, mm ±10 ±2.5 ±1.5 ±1.5 ±0.4
(in.) (±0.394) (±0.098) (±0.059) (±0.059) (±0.016)
Incident Angle, degrees, max 19 16 11 10 5
Marking Speed
4
characters/sec, max 450 450 450 450 450
