technical reference
SYNRAD FH Series Flyer Operator’s Manual Version 3.4
157
Marking System Resolution
Position Resolution, µm <15 <9 <6 <6 <3
(in.) (<0.0006) (<0.0004) (<0.0002) (<0.0002) (<0.0001)
Repeatability, mm 0.063 0.038 0.025 0.025 0.015
(in.) (0.0025) (0.0015) (0.0010) (0.0010) (0.0006)
Settling Time, small step -
1% of eld, µs <440 <440 <440 <440 <440
Orthogonality (any included
angle of a square gure), degrees 90°00' ±20' max
Input Specications
Input Power 30 VDC ±2.0 VDC @ 4 A, 8 A peak
Heat Load, generated by head (W) 90 nominal, 120 max
Continuous Beam Input Power, max (W) 125 mm lens – 40, all other lenses – 140
* Specications subject to change without notice.
1 FHFL30-xxx designates an FH Flyer head with a 3X (black) expander for 48-1/-2/-5 and Firestar f100 lasers. FHFL25-xxx
designates an FH Flyer with a 2.5X (silver) expander for Evolution 100/125 lasers. FHFL50-xxx designates a Flyer head with a 5X
(red) expander for Firestar v-Series and t-Series lasers. The “xxx” denotes a 370, 200, 125, or 80 mm lens or “U” for unfocused
(no lens included).
2 High-power 125 mm lens for use with lasers 40 W and higher.
3 The typical focal length (working distance) is marked on each lens mount. Because the actual working distance may vary from
lens to lens, it is important to provide a Z-axis adjustment between the FH Flyer marking head and the marking surface. Consult
your marking head’s Final Test Report for the actual measured working distance.
4 Based on a character height of ~3 mm and a 200 mm focusing lens.
General specications
Parameter
Environmental Specications
Operating Temperature 0 °C to 40 °C
Humidity 0–95%, non-condensing
Physical Specications
Length 21.46 cm (8.45 in.)
Width 13.72 cm (5.40 in.)
Height 13.69 cm (5.39 in.)
Height, including lens 15.60 cm (6.14 in.)
Weight, max 4.35 kg (9.6 lbs)
