able 6-13 Index/Tracker output conversion—all RTN lines grounded (sinking
current)
FH Index/Tracker I/O Connector Flyer DB-25 I/O Connector
Pin # Wire Color Function Pin # Function
1 Black RTN4 *2 OUT2–7_B
2 White OUT4 4 OUT4_A
3 Red OUT5 16 OUT5_A
4 Green RTN5 *2 OUT2–7_B
5 Orange RTN6 *2 OUT2–7_B
6 Blue OUT6 3 OUT6_A
7 White/Black OUT7 15 OUT7_A
8 Red/Black RTN7 *2 OUT2–7_B
* On the Flyer DB-25 User Interface connector, outputs OUT2–OUT7 share a common return—OUT2–7_B on Pin 2. This wiring
scheme assumes that RTN4–RTN7 are all tied to the I/O supply’s DC common or return side (FH outputs are sinking current).
Input/Output circuitry
Use Table 6-14 when all output lines (OUT4–OUT7) are connected to the I/O circuit’s DC voltage
supply (V+).
T
able 6-14 Index/Tracker output conversion—all OUT lines tied to V+ (sourcing current)
FH Index/Tracker I/O Connector Flyer DB-25 I/O Connector
Pin # Wire Color Function Pin # Function
1 Black RTN4 4 OUT4_A
2 White OUT4 *2 OUT2–7_B
3 Red OUT5 *2 OUT2–7_B
4 Green RTN5 16 OUT5_A
5 Orange RTN6 3 OUT6_A
6 Blue OUT6 *2 OUT2–7_B
7 White/Black OUT7 *2 OUT2–7_B
8 Red/Black RTN7 15 OUT7_A
* On the Flyer DB-25 User Interface connector, outputs OUT2–OUT7 share a common return—OUT2–7_B on Pin 2. This wiring
scheme assumes that OUT4–OUT7 are all tied to the I/O supply’s positive DC (V+) voltage (FH outputs are sourcing current).
