stand-alone
operation
SYNRAD FH Series Flyer Operator’s Manual Version 3.4
93
Conguration
3 Use a ruler marked in millimeters to set the proper Z-axis working distance from the bottom of the
focusing lens mount to the surface of the part. Refer back to Figure 3-5 in the Operation chapter.
Lase the mark
1 Check that all safety precautions discussed earlier such as safety glasses and shielding around the
beam area are in place.
Danger
serious
personal
injury
This product emits invisible infrared laser radiation in the 10.6 µm
CO
2
wavelength band. Since direct or diuse laser radiation can
inict severe corneal injuries, always wear eye protection when in
the same area as an exposed laser beam. Do not allow the laser beam
to contact a person. CO
2
lasers emit an invisible laser beam that is
capable of seriously burning human tissue.
Always be aware of the beam’s path and always use a beam block
while testing.
Warning
serious
personal
injury
Pressing the Mark Current File on Canvas button forces FH Flyer to
begin marking immediately after the mark le is downloaded into
RAM. Before pressing this button, ensure that all laser safety precau-
tions described in this manual have been followed.
During the time that FH Flyer is actively marking, the Launcher
window opens and displays mark progress and cycle time. In this
“quick mark” mode, the Launcher window closes as soon as the mark
is complete. To view cycle time information, click WinMark’s Mark
button to reopen the Launcher window.
2 Press the Mark Current File on Canvas button. The mark le you created is downloaded to the FH
Flyer head and the laser res the mark immediately.
Note: Launcher’s Preview window is blank because WinMark Pro is not generating microvector data
during the mark.
The le you downloaded to FH Flyer now resides in RAM and is also saved in the Filestore as Canvas.mkh.
Press F1 on the computer keyboard or click Start-F1 in the Launcher window to lase another mark. You can
hover your mouse pointer over the Mark button to verify the correct le is loaded into Flyer RAM.
An untitled le downloaded to Flyer will overwrite the current Canvas.mkh le. Save this le to the File-
store permanently by clicking WinMark’s Save Current File to Filestore button or right-click the Canvas.
mkh le in the Flyer Files window and choose Rename from the pop-up contextual menu. To archive this
le to your computer or server, open WinMark Pro’s File menu and select Save As… .
