INSTRUCTION MANUAL
16
5.4. CONNECTION OF THE MACHINE TO THE SOURCES OF ENERGY
1
2
1. Electric supply, into the electric cabinet from below, 2. Air supply hose is lead under the
covers, to the rear of the S-80 machine (see 5.4.2.)

aDANGER! Disconnect the electric current to the supply cable before

a

a

The terminals for connecon of the external supply cable to the S-80 unit are placed in
the electric cabin. The supply cable is lead under the electric cabin into the cabin.
Special aenon is to be paid to correct grounding of the machine. Make sure the
operang voltage of the machine corresponds to the supply voltage of the circuit. The
machine can be supplied with a voltage of 400 V/50Hz.
Check the correct connecon with the help of the circuit diagram supplied with the
machine. Compare the diagram with the values on the idencaon plate of the
machine.
