T-Drill S-80 - Clamping Device Maintenance and Adjustment

COLLARING MACHINE
65
S-80


The Manual Feed Table denes the clamping center Y-axis posion, because the MFT
does not have an adjustment of Y-axis direcon. 


1. Remove the posterior pneumac cylinder (1).
2. Open the locking screws of the toothed rack (2).
3. Place a gauge tube to the MFT. Adjust the clamps by the adjustment screw to grab the
gauge tube. Make sure to leave a stroke margin for the clamping cylinder (theorecal
1,5mm+1,5mm).
4. Tighten the locking screws of the toothed rack and the adjustment screw nuts.
1 2 3
Adjustment of the clamping center point
1
2
Lubricate the clamping device centering mechanism by grease nipples using a grease gun
once a month, use vaseline KLÜBER ISOFLEX TOPAS L152 (NLGI 2) or equivalent.
