T-Drill S-80 - Page 64

INSTRUCTION MANUAL
64
Interval Maintenance Lubricant / tool Note
1 month
The tool locking device
thread: Check the
lubricaon of the thread
once a month.
Use Wurth HSS 2000
grease spray or
equivalent.
Lubricate the thread if
required.
1 month
Check the spindle belts
for wear and ghtness
(3 pcs).
The belt must be able
to twist approximately
10°... 15°.
Do not overghten the
belts. (see 8.3. Toothed
belts of the S-80 unit)
3 months
Lubricate the spindle
lower end bearings
Vaseline: KLÜBER
ISOFLEX TOPAS L152
(NLGI 2) or equivalent
Service interval for 2
shi operaon and 5
days / week
3 months /
100 hrs
Lubricate the screw jack
ball screw drives of X, Y,
Z movements
Vaseline: Castrol Tribol
GR 4747/220-2 HT or
equivalent
Service interval for 2
shi operaon and 5
days / week
3 months /
100 hrs
Ball screw drives of X, Y,
Z movements
Vaseline: KLÜBER
ISOFLEX TOPAS L152
(NLGI 2) or equivalent
The gears are lubricated
for life.
3 months
The Hiwin slide blocks, 6
pcs on clamping device,
X, Y, Z movement 4 pcs
each.
(See separate Hiwin
manual for details)
Vaseline: KLÜBER
ISOFLEX TOPAS L152
(NLGI 2) or equivalent
Service interval for 2
shi operaon and 5
days / week
Lubricaon maintenance interval in irregular use: Lubricate aer every 30.000 work cycle
or 100 km, or at least every 6 months.



