T-Drill S-80 - Smaller S-80 Heads: Fork Tool 6560094; Drilling Collaring Tool Maintenance

COLLARING MACHINE
71
S-80

The special tool 6560094 is used to open and ghten smaller tools, that do not have a
hex head for the spanner.
The fork tool is fastened to the collaring head, to the boom of the drill core with two
hex bolts.
1. Fork special tool 6560094, 2. Tool cone jig 6560093
The Collaring tool is placed to the Tool cone jig, which is fastened to a vice bench
securely.

1. Top posion stopper, xed to the cone
1
2
3
2. Set screw for ghtening of the tool
3. Fixing surface of the tool. The at
surface of the head must be on the same
side as the set screw.
The drilling collaring tool is placed to the tool holder cone by pushing it into the cone
up to the stopper (1) and ghtened with the set screw (2). When ghtening turn the
collaring head from side to side a bit to make the sloped ghtening surface (3) align with
the set screw head.
