T-Drill S-80 - Collaring Tool Measuring Device 5560252

COLLARING MACHINE
51
S-80

Tool angles are tool specic. The collaring tool angle dierence changes when the tool
is disassembled and assembled again. A new tool needs to be measured and angle
informaon lled to the machine tool denion screen on control panel display.
3
6
4
5
1
2
1. Zero line, 2. Posioning peg, 3. Drive key (stopper), 4. Dial: Tool holder cone - drill core
angle dierence (S1 axis), 5. Dial: Drive wheel - drill core angle dierence (S2 axis), 6.
Collaring tool.


The measuring device gives you a rough value of the angles, the precise values are
received by posioning the tool on manual screen of the operators panel.
1
2
Measuring device from the inside: 1. Drive wheel axis piece, 2. Tool holder cone axis piece
