INSTRUCTION MANUAL
54
6.5.3. DRILLING COLLARING TOOLS
DCT tool has its own seng screen on Sengs - Tool Sengs:
Ø34 5560486
Adapter head
Ø19 5560477
Adapter head
Ø25 5560480
Adapter head
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
1
2
3
4
5
6
7
8
Drilling collaring tool parts: 1. Cone (retenon knob is xed to the cone), 2. Brake drum,
3. Adjuster cone, 4. Forming pin, 5. Pilot hole drill, 7. Locking screw, 8. Cone locking set
screw
