T-Drill S-80 - Main Parts of the Machine

COLLARING MACHINE
9
S-80
3.4. MAIN PARTS OF THE MACHINE
1
8
7
12
2
3
4
5
6
1
2
3
4
5
6
7
8
9
11
10
12
2
1 Machine main frame
2 MFT Manual Feed Table (Oponal equipment)
3 Clamping unit
4 Moving frame (slide set and frame)
5 Spindle
6 Tube support
7 Covers and doors
8 Front cover
9 Chip shield
10 Warning beacon
11 Control panel
12 Oil and chip tray (another oil tray is located inside the machine frame)
