COLLARING MACHINE
25
S-80
6.2.2.2.1. PROGRAMS
1
2
3 4
5
1 Tap to enter program screen
2 Program le list, downloaded from the computer (predened locaon).
3 Reads the acvated line program from the PC to the display
4 Saves (writes) the program changes to the PC
5 Program contents list:
Funcon
Funcon number denes what is to be done.
Funcon number 0-9 are reserved for the special commands.
From that on the rst number indicates how many stages the
funcon has, and the following number indicates what work cycle
with this amount of stages is done.
For example:
Funcon 30 tells that is has 3 stages and the rst work cycle is
done as described in the table.
Funcon 12 tells that it has 1 stage and the rst work cycles
collaring
Posion Only used when the machine is equipped with a feed table.
Rotaon
Only used when the machine is equipped with a tube rotaon
module. Expression 0-360 degrees.
Diameter
Diameter of the collar or a round hole. The ellipc pilot hole is
dened automacally by the size of the collar.
Height
The height of the collar from the outer surface of the tube. (The
outer surface is count from the tube outer diameter divided by 2.
The diameter value can be altered by adjusng the oset).
