13. APPENDIX
13.1. CAPACITY TABLE
With the aid of the capacity charts on the following pages you will be able to determine
the max. wall-thickness of the tube and select the right collaring head.

1. From the horizontal black row, nd the collar size you need, and from the vercal black
column the diameter of your run tube.
2. The intersecon of the horizontal and vercal rows will show you the max. wall
thickness of the tube. This value is not to be exceeded.

Ø6 Ø8 Ø10 Ø12 Ø15
Ø8
0.5 0.5
Ø10
0.8 0.8 1.0
Ø12
0.8 1.0 1.0 1.0
Ø15 0.8 1.0 1.0 1.0 1.2
Ø18 0.8 1.0 1.0 1.0 1.2
Ø22 0.8 1.0 1.2 1.2 1.5
Ø25 0.8 1.0 1.2 1.2 1.5
Ø28 0.8 1.0 1.2 1.2 1.5
Ø35 0.8 1.0 1.2 1.2 1.5
• 
¨NOT!¨ 



