6.2.2.1. BAR CHARTS SCREEN
NOT AVAILABLE.
6.2.2.2. MENU SCREEN
The available funcons depend on user level. Below shown as Supervisor user level:
1
2 3 4 5
6
7 8
12
9 10 11
1. Tap to go back to Main screen
2. Tap to enter Programs screen: Load, make and edit programs (6.2.2.2.1.)
3. Tap to enter Manual screen (6.2.2.2.2.)
4. Tap to enter Automac screen (6.2.2.2.3.)
5. Tap to enter Sengs screen (6.2.2.3.)
6. Tap to enter Alarms screen: All alarms will appear to this screen (6.2.2.4)
7. Tap to enter Users screen: Manage user informaon (6.2.2.5.)
8. Tap to enter Language screen: Change display language by tapping a ag on screen.
9. Tap to enter Counters screen: machine counters list (6.2.2.6.)
10. Tap to enter PLC data: inputs and outputs (6.2.2.7.)
11. Maintenance screen (T-Drill service only)
12. Tap to enter Bar Charts screen (6.2.2.1.) NOT AVAILABLE

