COLLARING MACHINE
23
S-80

Funcon
Funcon number denes what is to be done.
Funcon number 0-9 are reserved for the special commands.
From that on the rst number indicates how many stages the funcon has, and the
following number indicates what work cycle with this amount of stages is done.
For example:
Funcon 30 tells that is has 3 stages and the rst work cycle is done as described in
the table.
Funcon 12 tells that it has 1 stage and the rst work cycles collaring
Posion
Only used when the machine is equipped with an automac feed table.
With MFT & manual tube support: just for notes.
Rotaon
Only used when the machine is equipped with a tube rotaon module. Expression
0-360 degrees. With MFT & manual tube support: just for notes.
Diameter
Diameter of the collar or a round hole. The ellipc pilot hole is dened
automacally by the size of the collar.
Height
The height of the collar from the outer surface of the tube. (The outer surface
is count from the tube outer diameter divided by 2. The diameter value can be
altered by adjusng the oset).
PAUSE
Put the machine to PAUSE by pushing the “STOP” buon quickly, the buon will start
ashing to inform that the machine is paused. (To switch PAUSE o push “STOP” buon
again). The machine is in pause mode, if no one is logged in.
STEP MODE
The step mode is used to run the machine program step-by-step:
Put the machine to PAUSE by pushing the “STOP” buon quickly, the buon will start
ashing to inform that the machine is paused. (To switch PAUSE o push “STOP” buon
again).
Run the program step-by-step by pushing the “START” buon, one push is one step.
