6.1. DESCRIPTION OF THE CONTROL DEVICES

The main switch of the unit is placed on the electric cabin door. The main switch can be
locked with a padlock in order to prevent unauthorized use of the machine.
The power is switched on by turning the main switch to “ON” (I) posion. The power is
switched o by turning the main switch to “OFF” (O) posion.
When the power is switched “ON” the machine “OFF”-buon on the control panel is lit
red, and the start screen opens to the display.
6.1.2. CLAMP REMOTE CONTROL CB3
1
2
3
Clamp remote control: 1. Manual control ON-OFF, 2. Clamps close, 3. Clamps open.
The remote control is for posioning of the tube to the clamps: nal clamp ghtening is
done automacally when the work cycle starts. Turn machine to MANUAL from control
panel switch and acvate remote control from pendant switch (1).
L Ohere is a continuous pressure on the clamp control pneumatic line
to keep the tube from falling off the clamps when the emergency stop
is pushed!


