T-Drill S-80 - Manual Feed Table

COLLARING MACHINE
57
S-80
6.6. MANUAL FEED TABLE
1
2
3
Manual feed table parts: 1. Table frame, 2. Posioning device, 3. Posioner plate
This manual posioning table is designed for one certain 38 mm diameter bent tube and
two dierent sets of collars to it.
The manual posioning device is equipped with a two-stage posioning plate (“pin-to-
hole) and an angle and height adjustment to allow the bent tube to go through the S-80
machine.
The tube is clamped to the Manual Feed Table (MFT) and the collars are made to correct
posions using the horizontal posioning and angle posioner.
