Turn the main switch o (0). Lubricate the following points by the grease nipples, use a
grease gun:
1. The spindle bearing
Service interval for 2 shi
operaon and 5 days / week: 3
months.
21
2. S-80 unit inner spindle
conical roller bearings:
Open the cover on the spindle
side.
Lubricate with grease gun: two
strokes.
Service interval for 2 shi
operaon and 5 days / week: 1
month.
3. Lubricaon of the planetary
gear and needle bearing:
There are 2 grease nipples,
only one visible at the me.
The inner spindle (gear) must
be rotated 180°to reach the
other nipple. Rotate from the
upper belt, push the belt to
rotate with thumbs.
Lubricate with grease gun: two
strokes.
Service interval for 2 shi
operaon and 5 days / week: 1
month.
(The lower picture shows the
gear under the locking device).
!
