T-Drill S-80 - Settings Screen

INSTRUCTION MANUAL
30
6.2.2.3. SETTINGS SCREEN
The buons are dim when the user has no rights.
1
2 3 4 5
6
7
Tap to enter:
1. Machine sengs General machine sengs (6.2.2.3.1.)
2. Process sengs
Sengs for dierent processes of the machine: Milling, collaring,
trimming and drilling. (6.2.2.3.2.)
3. Tool sengs All tool sengs (6.2.2.3.3.)
4. Tool magazine Tool magazine holder and posion sengs (6.2.2.3.4.)
5. Posions Machine posion sengs (6.2.2.3.5.)
6. Servo motors: Adjustment parameters for the servo motors (6.2.2.3.6.)
7. References: Set axis references (6.2.2.3.7.) T-Drill service only
The buons are dim when the user has no rights.
