T-Drill S-80 - Page 53

COLLARING MACHINE
53
S-80
 = The drive key / stopper position is 90°
when the tool is placed in the magazine.
The pick up angles of the tool are
S1 = 90° + xx°
S2 = 90° + yy°
90˚
0˚
180˚
270˚
!
¨NOT!¨ 


The values are wrien to the 6.2.2.3.3. Tool
sengs screen table:
Fill in the values to the tool information
screen fields. (Tap numeric field to open pop-
up keypad).
!
!
!
