Axis name Movement / funcon
10-c= Cover of the tool magazine
Y-
Y+
Z+
Z-
X+
X-
20-x= Sideways direcon
20-y= Depth direcon
20-z = Up / down direcon
30-S1 = S-80 inner spindle
30-S2 = S-80 outer spindle
