T-Drill S-80 - Page 67

COLLARING MACHINE
67
S-80
Spindle, tool holder, peg and the dial gauge.

The collaring center is a programmable value of the clamp center.
Remove tube specic clamps. Aach a small dial gauge (with magnec leg) to the spindle
axle, and posion the gauge p to clamping device horizontal surface. Move the spindle
slowly (manual mode) to posion it to center of the clamping device.
Save the posion to the machine program.
12
1. Reference seng point (xed tool), 2. Tube / clamp center
