Tally T6090 - Component List

B-13
Appendix B: Recommended Spare Parts, Illustrated Parts Breakdowns, and Component Lists
Component # Description Part Number U1 Firmware – Ctl Processor 87C196 403054-01
Socket–PLCC 68-pin 731012
U4–U20 Array–Trans/Diode SMA4032 730980
U21 I.C. 74HCT14 403740-01 U22 I.C. X24C08 731069 U23 I.C. 74HCT74 403782-01 U24 Firmware – 87C750 081194
Socket I.C. 24-pin Slimline 403054-01
U26 I.C. LM324 402328-01 U27–U32 I.C. 3952 731071
Heatsink I.C. Dip 403883-03
RP1–RP17 Resistor Sip 510 8-pin Isol 403006-09 R1 R8 Resistor 120Ω 1/4W ±5% 400072-75 R2 R67 R74 Resistor 12KΩ 1/4W ±5% 400073-27
R3 Resistor 4.99KΩ 1/4W ±1% 402285-168 R4 R6 Resistor 121Ω 1/4W ±1% 402285-09 R5 R24 R53 Resistor 2.10KΩ 1/4W ±1% 402285-132 R7 R13 R60 R65 Resistor 10KΩ 1/4W ±1% 402285-201 R9 R10 R11 R14 R16 R42
Resistor 1KΩ 1/4W ±5% 730105
R12 Resistor 5.1KΩ 1/4W ±5% 400073-18 R15 Resistor 100KΩ 1/4W ±1% 402285-301 R17 R19 R22 R54 Resistor 3.3KΩ 1/4W ±5% 730106R20
Resistor 51KΩ 1/4K ±5% 400073-42
R25 R30 Resistor 100KΩ 1/4W ±5% 400073-49 R23 Resistor 237Ω 1/4W ±1% 402285-37 R26 R27 R31 R35 R75 R76 R77
Resistor 10KΩ 1/4W ±5% 730108
R28 Resistor 22Ω 1/4W ±5% 730259 R29 Resistor 16KΩ 1/4W ±5% 400073-30 R32 Resistor 100Ω 1/4W ±5% 730103 R33 Resistor 510Ω 1/4W ±5% 400072-90 R34 Resistor 2.49KΩ 1/4W ±1% 402285-139
R36 R48 Resistor 1megΩ 1/4W ±1% 402285-401 R37 Resistor 0.5Ω 1/4W 732161 R38 R51 R52 R55 R57 R62 R66
Resistor 24KΩ 1/4W ±5% 400073-34
R39 Resistor 24KΩ 330W ±5% 400073-61
R40 Resistor 20KΩ 1/4W ±5% 400073-32
Component # Description Part Number R41 R43 R44 R44A Resistor 24KΩ 20W ±1% 402285-230
R45 R46 Resistor 8.25KΩ 1/4W ±1% 402285-189 R46A Resistor 1.8KΩ 1/4W ±5% 400073-07 R47 Resistor 1.0Ω 5W 732163 R49 R50 Resistor 30.1KΩ 1/4W ±1% 402285-247 R56 Resistor 750KΩ 1/4W ±5% 400073-70
R58 R63 Resistor 13KΩ 1/4W ±1% 402285-212 R59 R64 Resistor 15KΩ 1/4W ±1% 402285-218 R68 R69 Resistor .3Ω 1W 403026-02 R70 R71 Resistor 1.0Ω 1W 403026-03 R72 R73 Resistor .5Ω 1W403026-06
R18 NOT INSTALLED C26 C35 C36 NOT INSTALLED U3 717 J901 NOT INSTALLED U2 U25 I.C. HamVLSI 52-pin 080336 C9 C12 Cap .01MFD 50V 10% SMD 731545 C1 C2 C4-C7
C13 C14 Capacitor 4700PFD 50V ±10% 402910-133 C3 C15 C18-C20 C23 C25 C27 C28 C30 C31 C34 C37 C46 C51C53 C55 C57 C59 C61
Capacitor .1MFD 50V 730142
C8 C21 Capacitor 22MFD 25V TANT 730120 C10 C11 Capacitor 1000PFD 50V ±10% 731017 C15A Capacitor 1200PFD 100V ±10% 402910-126 C16 C17 Capacitor 33PFD 50V ±10% 730617 C22 C24 C29 Capacitor 120PFD 50V ±10% 730168
C28A Capacitor 1MFD 50V 402172-07 C32 Capacitor 10MFD 25V ALUM 730442 C33 Capacitor 100MFD 25V ALUM 402172-58 C38 C40 C41 C45 C47 C48 C63
Capacitor 1200PFD 100V ±10% 402910-126
C39 C42 C43 C44 C52 C54 C56 C58 C60 C62
Capacitor .1MFD 100V ±10% 402910-149
C64 C65 Capacitor 1800MFD 63V 731750 C66 Capacitor 100MFD 63V 731083 C67 Capacitor 10MFD 63V 731708
CR1 CR21 Diode 1N914B 400836-04 CR2-CR18 Diode Zener 1N5347B 10V 400049-45 CR19 Diode Zener 1N5908 731072
