B-14
Maintenance Manual
Component # Description Part Number
CR22 Rectifier 2N6505 732160
CR23 CR24 Diode UF4002 403880-02
CR25 Diode Zener 1N5359A 24V 400049-80
CR26 Diode 1N4003 400698-03
CR27 Diode MUR820 731075
CR28 Diode Zener 1N5255B 28V 731747
CR29 Diode 1N4751A 30V 400664-61
Y1 Crystal 12.288MHZ para fund. 731243
Q1 Transistor 2N3904 401340-01
Q2 Transistor MJE800 400951-01
Q3 Transistor 2N5550 402278-01
Q4 Transistor 2N4403 731690
VR1 Regulator–Voltage LM317 402668-01
VR2 Regulator–Voltage LM2576HVT-5 731080
VR3 Regulator–Voltage 7912 401444-01
RT1 Thermistor 730099
L1 Filter-EMI Suppressor 730097
L2 L3 Inductor 150UH 731522
L4-L15 Bead–Ferrite, leaded 730098
L16 Inductor 22UH 731098
J2 Connector 3-pin 730163
J3 Connector 2-pin 732164
J17 Connector Male 32-pin Din 731733
J302 Connector Power 4-pin 731119
J501-J503 Connector 5-pin 731731
J601-J604 Connector Phone 4-pin 403760-01
J703 J704 Connector 44-pin 402330-02
J801 Connector 6-pin 730012
