Technogym ELLIPTICAL

To Next Page

To Previous Page

Remove the rod [59] as shown in the

gure.

Secure the rod to the equipment with

a strap as shown in the gure

TECHNOGYM ELLIPTICAL Technical Service Guide

Rev. 1.1

- 94 -
