the controller
The marking head cable is cut
Check the cable condition
Can happen only during
marking controller initialisation
A mechanical blockage
prevents the machine to go to
its origin point
Check that the path of the
marking head is free then
restart the controller
With no power on, check that
the machine can reach its origin
position freely
The detection card is faulty
If still at fault, call After Sales
Service
Error 14 : Origin X and Y error
The pin assembly is
mechanically stopped by an
outside obstacle
Check that the path of the
marking head is free then
restart the controller
Can happen only after a first or
n marking
The detection elements are
faulty
Check that the detection tabs
are not bent, and so not
passing inside the detectors
and restart the controller
The detection card is faulty
Contact After Sales Service
Error 15 : Origin X error
The pin assembly is
mechanically stopped by an
outside obstacle
Check that the path of the
marking head is free then
restart the controller
Can happen when starting,
after the first marking or after n
markings
X detection element is faulty
Check that the X detection tab
is not bent, and so not passing
inside the detector and restart
the controller
The detection card is faulty
Contact After Sales Service
