Error 16 : Origin Y error
The pin assembly is
mechanically stopped by an
outside obstacle
Check that the path of the
marking head is free then
restart the controller
Can happen when starting,
after the first marking or after n
markings
Y detection element is faulty
Check that the Y detection tab
is not bent, and so not passing
inside the detector and restart
the controller
The detection card is faulty
Contact After Sales Service
Error 17 : Origin Z Sensor error
No Z Sensor Axis
The Z sensor origin detection
element is faulty
Configure your marking
machine without Z Sensor
Contact After Sales Service
Error 18 : Origin Z electric error
NO Z Electric
The Z electric origin detection
element is faulty
Configure your marking
machine without Z Electric axis
Contact After Sales Service
Error 19 : Plate charger origin
error
No plate charger
The plate charger origin
detection element is faulty
Configure your marking
machine without plate charger
Contact After Sales Service
Error 20 : Tor Z origin error
No Z Tor
The Tor z origin detection
element is faulty
Configure your marking
machine without Tor Z
Contact After Sales Service
Error 21: D axis origin error
No D axis
The D axis origin detection
element is faulty
Configure your marking
machine without D axis
Contact After Sales Service
Error 23 : Z sensor error :
The Z sensor detector has
covered its full course without
Configure again Z Sensor
