Chapter 2 Basic Unit Specification
8. Built-in memory and memory card
2-33
8 Built-in memory and memory card (TP03-1ME)
Built-in memory
Type Saving content Saving place
1. User program (20/30 type: 0~8K, 40/60type: 0~16K)
2. File register (D2000~D7999, 6K)
In total: 16K
Memory
for
program
3. Remark (0~16K)
System specification (0~20)
Built-in flash
memory (power fail
have no impact on
the data)
Non-retentive
1. Input relay X, output relay Y, general auxiliary relay M,
general state S
2. Timer contact and timing coil.
3. General counter contact, counting coil and reset coil.
4. General data register for present value.
5. Register for present value of timer.
6. Register for present value of general counter.
Built-in RAM
(data will be lost as
power fails)
Data register
retentive
1. Retentive auxiliary relay M, retentive state S.
2. Contact and coil of accumulating timer T.
3. Contact, counting coil and reset coil of retentive counter
and high speed counter.
4. Retentive register D for present value
5. Register for present value of accumulating and 1ms timer
T.
6. Register for present value of retentive counter and high
speed counter.
7. Special register (M8000~M8511, D8000~D8511)
Built-in RAM
(data will be saved
by lithium battery
as power fails)
Memory card (TP3-1ME)
Type Saving content Saving place
1.User program (20/30 type: 0~8K, 40/60type: 0~16K)
2. Remark (0~16K)
In total: 16K
Memory for
program
3. file register (D2000~D7999,6K)
4. System specification (0~20)
Built-in flash
memory
5. Special register (M8000~M8511, D8000~D8511)
Note:
A. The program in built-in memory will be performed as memory card (TP3-1ME) is not used.
B. The memory card (TP3-1ME) is pluggable as power is off.
C. When power is ON, the program will be automatically transmitted from memory card
(TP3-1ME) to built-in memory.
D. Software TP3-PC or TP3-PDA can read the data in built-in memory or memory card
(TP3-1ME).
