Chapter 8 Special Relay
Special relay
8-16
AD/DA (M)
AD/DA (D)
Device No. Function Operation
8256
number of modules
(TP02-4AD+)
8257
number of modules
(TP03-AD)
8258
Number of channels
(TP02-DA modules)
8259
Number of channels
(TP03 DA modules)
As for the basic unit (20/30 points, SR
type ), only one group either D8256 &
D8258 or D8257 & D8259 is available for
setting.
8260 AD filter mode
8261 AD1~4 channel mode set
8262 AD5~8 channel mode set
8263 AD9~12 channel mode set
8264 AD13~16 channel mode set
8265 AD17~20 channel mode set
8266 AD21~24 channel mode set
8267 AD25~28 channel mode set
8268 AD29~32 channel mode set
8269 AD33~36 channel mode set
8270 AD37~40 channel mode set
8271 AD41~44 channel mode set
8272 AD45~48 channel mode set
8273 AD49~52 channel mode set
8274 AD53~56 channel mode set
8275 AD57~60 channel mode set
8276 Reserved
8277 DA1~4 channel mode set
8278 DA5~8 channel mode set
8279 DA9~10 channel mode set
8381 DA channel 1data
8382 DA channel 2data
8383 DA channel 3data
Device No. Function Operation
8257 Total quantity of AD modules is wrong
8258
Total quantity of DA module channel is
wrong
