Trial Run
Troubleshooting 6-6
3.5 Troubleshooting procedure
3.5.1 Troubleshooting procedure - 1
M register D register
No. Function No. Error code description
Continue
to operate
8060
Expansion card
error
8060
Error code :200x: Expansion card not adapt to
x: card install in fact
1:TP03-6AV
2:TP03-485RS
3:TP03-232RS
4:TP03-2AI
5:TP03-2TI
6:TP03-10P
6006:no communication card
Y
8061
PC hardware
check
8061
Error code 0000: No error
6101: RAM error
6102: ROM error
6103: Basic unit I/O bus error
6104: User program error
6105: watchdog time detecting over
time
N
8063
Communication
error
8063
6301:DTLK error
6302:RMIO error
Y
8064 Parameter error 8064
Error code 0000: No error
6401: program and parameter is not
corresponding
6402: register capacity set error
6409: other error
N
8065 Syntax error 8065
Error code 0000: no error
6501: instruction address error
6504: pointer repeated
6505: device address is beyond range
6506: using undefined instruction
6507: Pointer error
6508: Interruption pointer error
6509: other
N
8066 Program error 8066
Error code 0000: no error
6603: MPS continuously used for
more than 8 times
6604: MPS MRD MPP relation error
6605: STL continuously used for
more than 10 times
6606: no known label
6607: Main program has I and SRET
6609: CALL has more than
16 levels
nest.
6610: for next are not corresponding
6611: with JCS and without JCR
6612: with STL and without RET
6613: with MC and without MCR
6614: with SMCS and without SMCR
6615: with I and without IRET
6616: MC, MCR I, SRET between
6617:for,next has more than 16 levels
nest.
6618: no end
6621: other error
N
