Chapter 2 Basic Unit Specification
1. Function
2-3
Type
Item
-14S -20S -26S -36S -20M 30M -20H 30H -40H -60H
When Y1 is set to count the output pulse, X3 can not be set as high speed counter.
As for M type, if the frequency exceeds specified one, the output states are maybe not right.
※3: The basic units of 20/30 points can, through setting special registers D8256 & D8258 or D8257 &,
choose the analog modules either TP02 serie s or TP03 series for expanding. While basic units o
40/60 points can set through D8256~ D8259 to expand TP02 series and TP03 series analog
modules which are both available for them at one time.
1.2 AC type Power supply specification
Type
Item
-14S -20S -26S -36S -20M -30M -20H -30H -40H -60H
24Vdc terminal for
external using
250mA(with short circuit
protection)
300 mA(with short
circuit protection)
500 mA(with short circuit
protection)
Power supply voltage 85 ~264 VAC
Operation
When the supplied power increases to 75~85VAC or above, TP03 will RUN,
which decreasing to 70VAC or less, TP03 will stops. The power failure lasting
within 10ms will not affect TP03 normal operation.
Consumption power 30VA 50VA
1.3 DC type Power supply specification
Type
Item
-40H -60H
24VDC terminal No
Power supply voltage 24V DC
Operation
When the supplied power increases to 19.2VDC or above, TP03 will RUN, while
decreasing to 19VDC or less, TP03 will stop. The power failure lasting within
10ms will not affect TP03 normal operation.
Consumption power 30W
