Chapter 8 Special Relay
Special relay
8-12
High speed and position (M)
PWM output（D）
*Note: S type has no function about PWM, M type only can be set to 0, H type can be set to 0,1,2.
Expansion （M）
Device No. Function Operation
8130
F55(HSZ) High speed counter zone
compare mode
8131 Finish flag for F55
8132 F55(HSZ),F57(PLSY) speed mode
8133 F55,F57 performing end flag
8134 Reserved
8135 Reserved
8136 Reserved
8137 Reserved
8138 Reserved
8139 Reserved
8140
FNC156(ZRN)CLR signal output
enable
8141 Reserved
8142
eserved
8143 Y000 pulse output finished Available since V1.6
8144 Y001 pulse output finished Available since V1.6
8145 Y000 pulse output stops
8146 Y001 pulse output stops
8147
Y000 pulse output monitoring
(busy/read)
8148
Y001 pulse output monitoring
(busy/read)
8149 Reserved
Device No. Function Operation
8158 PWM Y0 time base
8159 PWM Y1 time base
0： 1ms
1： 0.1ms
2： 0.01ms
Device No. Function Operation
8160 F17(XCH) SWAP
8161 8 octal processing mode (F76,80,83,84, 87,188)
8167 F71(HKY)HEX data processing
8168 F13(SMOV)DE HEX processing
