Chapter 5 Wiring
Basic unit wiring
5-4
2.2
Input wiring
Input signal has
two methods to
be wired for DC input: SIN
K and SOURCE mode.
◎
Sink = current inputs share
the common
Source = Current outputs share t
he common
Wiring
◎
A. SINK
mode
Input equivalent c
ircuit.
Wiring circuit
S
B. SOURCE
mode
Input equivalent c
ircuit.
Wiring circuit
Insulation circu
it: PL
C internal circuit photo
◎
-coupling i
nsulted with Input m
odule.
102
104
