Chapter 2 Basic Unit Specification
4. High speed input
2-24
4 High speed counter
4.1 General characteristic of high speed counter
Input requirements:
A. the duty circle for the input form should be 1:1;
B. Low voltage level should be less than 9V.
C. The respnding frequency of the high speed counter differs from high /low voltage level.
Frequencty
Input teminal High voltage level
-14S -20S -26S -36S -20M -30M -20H -30H -40H -60H
1 Phase 15v~20v 10 KHz 100 KHz
X000~X003
2 Phase 15v~28.8v 10 KHz 50 KHz
X004~X005
1Phase/2
Phase
15v~28.8v Unused 5 KHz 5 KHz
The above requirement should be met, or the responding frequency will be less or the counting
data would be wrong.
4.2 Number for Built-in high speed counter
The number is as following:
TP03M/H type
1phase 1 input counting 1phase 2 inputs counting 2phases 2 inputs counting
C235 C236 C237 C238 C239 C240 C241 C242 C243 C244 C245 C246 C247 C248 C249 C251 C252 C253 C254
X000 U/D U/D U/D U U U A A A
X001 U/D R R D D D B B B
X002 U/D U/D U/D R R R A R
X003 U/D R R U B
X004 U/D U/D S D R
X005 U/D R S R S S
U: Up-counting
D: Down-counting
R: Reset
S: Set
A: A Phase
B: B Phase
C250 / C255 are reserved.
TP03SR type
1phase 1 input counting 1phase 2 inputs counting 2phases 2 inputs counting
C235 C236 C237 C238 C241 C242 C246 C247 C251 C252 C253
X000 U/D U/D U U A A
X001 U/D R D D B B
X002 U/D U/D R R A
X003 U/D R B
U: Up-counting
D: Down-counting
R: Reset
A: A Phase
B: B Phase
C239/C240/C243/C244/C245/C248/C249/C250/C254/C255 are reserved.
