Chapter 1 TP03 Introduction
Introduction
1-11
4 OP07/08-TP03 cable (TP03-302MC) specification
TP03-302MC D-SUB/MINI DIN pin definition and internal connection:
D-SUB 9pin(Female)
(OP07/08)
MINI DIN 8pin(Male)(TP03 PG (PC/PDA) port)
definition pin pin definition
N.C 1
TX+ 2 2 RX +
RX+ 3 7 TX +
N.C 4 6 GND
GND 5 3 GND
N.C 9 8 GND
Vcc 6 5 Vcc
TX- 7 1 RX -
8 4
RX-
TX -
6
1
4
7
2
3
8
5
9
3
6
45
21
7 8
9PIN(Female)
8PIN(Male)
Shield
OP07/08(TP03-302MC)
D-SUB 9 pin (Female)
MINI DIN 8pin (Male)
OP07/08
TP03
(PC/PDA port)
1.8m
