Chapter 3 Expansion unit specification
expansion unit 3-1
Chapter 3 Expansion unit specification
1 Digital expansion unit
1.1 General specification
Type
Item
TP02
-16EXD
TP02
-16EYR
TP02
-16EYT
TP02
-16EMR
TP02
-32EMR
TP03
-16EMR
TP03
-16EMT
TP03
-16EYR
TP03
-16EYT
TP03
-16EXD
Expansion unit
outline
Brick type
Input point 16 0 0 8 16 8 8 0 0 16
Output point 0 16 16 8 16 8 8 16 16 0
Terminal block Unremovable
Dimension
( WxHxD)
64 x 90 x 76mm
110 x
90 x 76
mm
57 x 90 x 83 mm
Operation
temperature
0 ~ 55℃ (32~131F)
Storage temperature -25 ~ +70℃
Relative humidity Level RH1，30~95% (non-condense)
Pollution degree 2 (IEC 60664)
Installation class II
Enclosure IP20
Anti-erosive No erosive gas
Altitude Operation: 0 to 2,000m (0 to 6,565 feet) Transport:0 to 3,000m (0 to 9,840 feet)
Vibration Resistance Mounted on a DIN rail：10 to 57Hz amplitude 0.075mm, 57 to 150Hz acceleration
9.8m/sec
2
(1G) 2 hours per axis on each of three mutually perpendicular axis;
Mounted on a panel surface：2 to 25Hz amplitude 1.6mm, 25 to 100Hz acceleration
39.2m/sec
2
(4G) Lloyd’s 90 minutes per axis on each of three mutually perpendicular
axis.
Shock Resistance 147 m/sec2 (15G), 11 m sec duration, 3 shocks per axis, on three mutually
perpendicular axis (IEC61131)
Noise immunity 1,000Vpp，1us @30 to 100 Hz
Dielectric withstand 1,500VAC > 1mins between all terminals to ground ( for AC power supply )
Dielectric withstand 500VAC > 1mins between all terminals to ground ( for DC power supply )
Insulation resistance 500V DC @> 10M ohm between all terminals to ground
Grounding 100 ohm or less
