Tektronix DPO4000 Series - Taking Manual Measurements with Cursors

Display Waveform Data
9. Push Position to enable multipurpose knob a
to make vertical position adjustments.
Coupling
DC
Invert
Off
Bandwidth
Full
Fine Scale
100mV/div
Offset
0.00V
Position
0.00 div
Probe
Setup
1X
NOTE. You can also use the position knob on the
front panel to do this.
On the side-bezel menu, choose Set to 0 divs
to set the vertical position to the center of th e
screen.
For more information on vertical position, see
the Quick Tips below.
126 DPO4000 Series User Manual
