Tektronix DPO4000 Series User Manual

Application Examples
5. Turn multipurpose knob a to select channel 2.
6. Select Amplitud e.
Amplitude
7. Calculate the amplifier gain using the following
equations:
Gain = (output amplitude ÷ input amplitude) =
(3.155 V ÷ 130.0 mV) = 24.27
Gain (dB) = 20 x log(24.27) = 2 7.7 dB
DPO4000 Series User Manual 209
