Menus and dialog boxes
The Acquisition configuration menu
Use this configuration menu to set parameters for acquiring waveform data points and to enable XY mode.
T
o open the Acquisition menu, double-tap the Acquisition badge on the Settings bar.
The Acquisition menu fields and controls
Displayed fields and controls can change depending on menu selections.
Field or control Description
Run/Stop
Toggles the oscilloscope between constant acquisition (Run) and no acquisitions (Stop). When
stopped, the oscilloscope shows waveforms from the last completed acquisition.
Single/Seq
Acquires a single acquisition or a set number of acquisitions, then stops.
Clear
Erases acquired waveform data points from memory. Applies to all live acquisition waveforms.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 100

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
