Tektronix MDO34 User Manual

Field or control Description
Help Use to open the Help viewer and display current instrument software and option license information.
See Help (Help menu) on page
191.
See About (Help menu) on page 191.
Recall configuration menu (File menu)
Use this menu to recall (load) reference waveforms and instrument setups.
Drive name Drive letter Drive or physical USB port location
Root drive Instrument Storage
User-accessible memory on the oscilloscope
Front panel E
USB 2.0 (top)
F USB 2.0 (bottom)
Rear panel G USB 2.0
H USB 2.0 device port provides USBTMC support
Network location I through Z Network storage locations
To open the file Recall configuration menu:
1. T
ap File on the menu bar.
2. Tap Recall to open the Recall configuration menu.
Recall configuration menu fields and controls
Field or control Description
File type to open (tabs) Tabs on the left let you set which type of file to recall (Waveform or Setup).
Directory structure The Name column lists the directory structure, opening at the root (/) level. Use to quickly navigate to a
file.
T
ap to list the contents of the directory in the Name pane.
Tap the + button to display the directory and any subdirectories under it. Tap the - button to close that
directory structure.
Drag the scroll bar up and down to show more entries.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 176

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
