Tektronix MDO34 User Manual

To add a measurement, select the input source or sources, select the measurement, and tap the Add button. The measurement is added
to the Results bar
.
To change individual measurement settings, double-tap the Measurement badge to open a configuration menu for that measurement. See
Measurement configuration menu on page 111.
Add Measurements menu fields and controls
Field or control Description
Measurement description
(graphic and text)
Shows a graphic and short description of the selected measurement. Use this information to verify that
the selected measurement is correct for what you want to measure.
Source Selects the measurement source. If the measurement requires more than one source (for example,
Skew
, Phase, or many Power measurements), the menu shows two source fields from which to select.
Add button Adds the selected measurement as a measurement badge to the Results bar.
Standard measurement panels
Panel Description
Amplitude Measurements
panel
Lists the available amplitude measurements. See Amplitude Measurements panel on page 102.
When a digital source is selected, this panel is not available.
Time Measurements panel
Lists the available time measurements. See T
ime Measurements panel on page 104.
Other Measurements
Lists the available other measurements. See Other Measurements panel on page 105.
Power Measurements
Advanced Power Analysis (optional). Provides measurements for power quality, harmonics, slew rate,
switching loss, safe operating area, ripple, and modulation analysis measurements. See The Power
Measurements panel (optional) on page 106.
Amplitude Measurements panel
The Amplitude Measurements panel lists available amplitude-related measurements that you can take on analog channel signals, math
waveforms (time-domain), and reference waveforms. Amplitude measurements are not available for digital signals.
T
o open the Amplitude Measurements panel:
1. Tap the Measure button.
2. Tap the Amplitude Measurements panel.
To add a measurement to the Results bar:
1. Select the signal source.
2. Select a measurement.
3. Tap Add.
The Amplitude Measurements panel measurements
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 102

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
