Tektronix MDO34 User Manual

Field or control Description
Mark When • < Limit: A pulse width is less than the specified time limit.
• > Limit: A pulse width is greater than the specified time limit.
• = Limit: A pulse width is equal to the specified time limit.
• ≠ Limit: A pulse width does not equal (is greater than or less than) the specified time limit.
• Inside Range: A pulse width is in the specified time range.
• Outside Range: A pulse width is outside of the specified time range.
Level Sets the amplitude level that the signal must pass through to be considered a valid transition.
Set to 50% Sets the threshold at 50% of the measured signal transition range. 50% is calculated as (Top +
Bottom)/2.
Time Limit Sets the time period condition to be met.
High Time Limit Sets the longest acceptable pulse width time period for the range condition.
Only available when Mark When = Inside Range or Outside Range.
Low Time Limit Sets the shortest acceptable pulse width time period for the range condition.
Only available when Mark When = Inside Range or Outside Range.
Polarity Sets the polarity of the pulse to detect (positive pulse only, negative pulse only, or a positive or
negative pulse).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
T
rigger
Sets the current oscilloscope trigger settings to match the search criteria.
Other search types
Bus Search configuration menus on page 135
Edge Search configuration menu on page 152
Logic Search configuration menu on page 153
Rise/Fall T
ime Search configuration menu on page 156
Runt Search configuration menu on page 158
Setup and Hold Search configuration menu on page 159
Timeout Search configuration menu on page 160
Rise/Fall Time Search configuration menu
Use the Rise/Fall Time search to mark occurrences where the rise or fall time is less than, greater than, equal to, or not equal to a
specified time limit.
To create a new rise/fall time search:
1. Tap Search.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 156

Tektronix MDO34 Specifications

General

Analog Channels	4
Sample Rate	2.5 GS/s
Record Length	10 Mpoints
Mixed Domain Analysis	Yes
Waveform Capture Rate	>280, 000 wfms/s
Spectrum Analyzer Frequency Range	9 kHz to 3 GHz
Vertical Resolution	8 bits
Input Coupling	AC, DC, GND
Operating Temperature	0°C to +50°C
Digital Channels	16
Connectivity	USB, LAN, HDMI
Arbitrary Function Generator	50 MHz
Trigger Types	Edge, Pulse Width, Runt, Logic, Setup/Hold, Rise/Fall Time, Video
Input Impedance	1 MΩ
Maximum Input Voltage	300 Vrms
Dimensions	140 mm
Weight	4.5 kg
Bandwidth	100 MHz, 200 MHz, 350 MHz, 500 MHz
Display	10.1-inch capacitive touch HD display
Voltmeter	4-digit
